CLI commands
bandwidth control internet-port normal
Supported on: MSM710 MSM730 MSM750 MSM760 MSM765zl
bandwidth control internet-port normal <min-tx-%> <min-rx-%> <max-tx-%> <max-
rx-%>
Sets the bandwidth rates (Tx minimum, Tx maximum, Rx minimum, and Rx maximum) for traffic
classed as Normal.
bandwidth control internet-port very-high
Supported on: MSM710 MSM730 MSM750 MSM760 MSM765zl
bandwidth control internet-port very-high <min-tx-%> <min-rx-%> <max-tx-%>
<max-rx-%>
Sets the bandwidth rates (Tx minimum, Tx maximum, Rx minimum, and Rx maximum) for traffic
classed as Very High.
ip route gateway
Supported on: MSM710 MSM730 MSM750 MSM760 MSM765zl
ip route gateway<destination>/<mask> <gateway> <[metric]>
Adds a static route.
no ip route gateway <destination>/<mask> <gateway> <[metric]>
Removes the specified static route.
Parameters
<destination> Traffic addressed to this IP address will be routed.
<mask> Indicates the number of bits in the destination address that is checked for a
match.
<gateway> Indicates the IP address of the gateway the service controller will forward
routed traffic to. The gateway address must be on the same subnet as one
of the available interfaces (Internet port or LAN port).
<metrix> Indicates the priority of a route. If two routes exist for a destination
address then the service controller chooses the one with the lower metric.
firewall mode
Supported on: MSM710 MSM730 MSM750 MSM760 MSM765zl
firewall mode (high|low|none)
Sets the firewall mode.
Parameters
high Permits all outgoing traffic. Blocks all externally initiated connections.
low Permits all incoming and outgoing traffic, except for NetBIOS traffic. Use
this option if you require active FTP sessions.
none Disables the firewall.
2-41
