7. Install the access panel
8. Do one of the following:
Orient the server back in tower mode .
Install the server into the rack .
9. Connect all peripheral cables to the server.
10. Connect each power cord to the server.
11. Connect each power cord to the power source.
12. Power up the server.
ResultsResults
The installation is complete.
Serial port optionSerial port option
Install the serial port option to enable communication to physical serial devices. You can also use the serial connection to remotely
access the system BIOS and view POST error messages.
SubtopicsSubtopics
Installing the serial portInstalling the serial port
Installing the serial portInstalling the serial port
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a hex screwdriver available.
About this taskAbout this task
CAUTION:CAUTION:
A discharge of static electricity from a finger or other conductor might damage system boards or other static-sensitive
