Cable part numberCable part number ColorColor FromFrom ToTo
P54092-001 Blue Boot device signal connector PCH LP SlimSAS port 1
P54089-001 Orange Boot device power connector NS204i-u power connector
Option kit: P48403-B21
OCP upgrade cablingOCP upgrade cabling
OCP bandwidth upgrade cablingOCP bandwidth upgrade cabling
The OCP bandwidth upgrade cable are required to support a x16 OCP expansion option.
Cable part numberCable part number ColorColor FromFrom ToTo
1
1
1
