20. Connect each power cord to the server.
21. Connect each power cord to the power source.
22. Power up the server.
ResultsResults
The installation is complete.
Processor heatsink assembly optionProcessor heatsink assembly option
SubtopicsSubtopics
Processor cautionsProcessor cautions
Installing the processor heatsink assemblyInstalling the processor heatsink assembly
Processor cautionsProcessor cautions
CAUTION:CAUTION: To avoid damage to the processor or system board, only authorized personnel should attempt to replace or
install the processor in this server.
CAUTION:CAUTION: To prevent possible server malfunction and damage to the equipment, multiprocessor configurations must
contain processors with the same part number.
CAUTION:CAUTION: The pins on the processor socket and on the processor are very fragile and easily damagedThe pins on the processor socket and on the processor are very fragile and easily damaged . To avoid
component damage, do not touch these pinsdo not touch these pins. Any damage to them might require replacing the system board and/or
processor.
IMPORTANT:IMPORTANT: Processor socket 1 must be populated at all times or the server does not function.
IMPORTANT:IMPORTANT: If installing a processor with a faster speed, update the system ROM before installing the processor. To
download firmware, go to the Hewlett Packard Enterprise Support Center website ( ).
Installing the processor heatsink assemblyInstalling the processor heatsink assembly
PrerequisitesPrerequisites
Before perform this procedure:
Make sure that the compatible fans are installed .
Make sure that you have a T-30 Torx screwdriver available.
About this taskAbout this task
This server supports two heatsink options:
Standard heatsink (P47223-B21)
Performance heatsink (P47224-B21)
Processors with TDP equal to or greater than 195 W require performance heatsinks.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
