HPE ProLiant ML350 Gen11

System board componentsSystem board components
ItemItem DescriptionDescription
1 Chassis intrusion detection switch connector
2 CPU 2 MCIO port 2
3 CPU 2 MCIO port 1
4 Stacked, dual USB ports
5 Slot 15 OCP storage backup power connector
6 Secondary riser connector
7 Energy pack connector
8 NS204i-u power connector
9 Tertiary riser sideband connector
10 Auxiliary power connector for the secondary riser
11 Serial port connector
12 Slot 15 OCP port 1
13 Slot 15 OCP port 2
14 Auxiliary power connector for the primary riser
15 Primary riser connector
16 DisplayPort connector
17 Slot 14 OCP port 2
18 PCH LP SlimSAS port 2
19 PCH LP SlimSAS port 1
20 System battery
21 Front I/O & USB 3.2 Gen 1 port connector
22 Optical drive SATA-power connector
1
2
2
HPE ProLiant ML350 Gen11 Server User Guide 17
