4.5.2 Removing the Pallet
Context
● Wear protective gloves when unpacking the device.
● Choose railways, sea, or a road with good conditions during transportation. No
excessive tilt or jolt is allowed during transportation.
● Use a pallet truck to transport the cabinet secured to a wooden base to the
installation position. Insert the forks of the pallet truck in the middle position
to ensure balance.
● To prevent shocks or falls, move the cabinet gently.
● After placing the cabinet in the installation position, unpack it and take care to
prevent scratches. Keep the cabinet steady during unpacking.
Procedure
Step 1 Remove the packing materials such as the carton, stretch wrap, foam, condenser
protection cardboard, and plastic bags.
Step 2 Check the accessories against the accessory list.
Step 3 Remove the three bolts from each of the four corner
ttings (one bolt for
connecting the corner
tting to the pallet). Then remove the outdoor unit from
the pallet, as shown in Figure 4-39.
Figure 4-39 Removing the bolts connecting the bracket angles and the pallet
----End
NetCol5000-A050 In-row Air Cooled Smart Cooling
Product
User Manual 4 Installation
Issue 08 (2021-09-17) Copyright © Huawei Technologies Co., Ltd. 69
