C.3 NetCol500-A080 Electric Control Box Layout
Figure C-5 NetCol500-A080 electric control box (without a temperature control
intelligent monitoring board)
(1) PE bar (2) Fan switch (QF1)
(3) Receiver heater/Water cooling module
(QF2)
(4) Fan terminal
Figure C-6 NetCol500-A080 electric control box (with a temperature control
intelligent monitoring board)
