Huawei NetCol5000-A050 - CAN Teamwork + FE Monitoring

Figure 4-91 Connecting communications cables
----End
4.9.8.3.2 CAN Teamwork + FE Monitoring
Step 1 Connect teamwork and monitoring communications cables.
Networking
CAN Teamwork FE Monitoring
Protocol CAN Modbus-TCP/SNMP
Description One teamwork network
supports a maximum of 32
units. On the Teamwork
Settings screen of the display
modules of the rst and last
units, set Enable teamwork
CAN resistor to Yes.
-
NO TE
Customers can purchase a switch and NetEco as the monitoring system.
NetCol5000-A050 In-row Air Cooled Smart Cooling
Product
User Manual 4 Installation
Issue 08 (2021-09-17) Copyright © Huawei Technologies Co., Ltd. 114
