Huawei NetCol5000-A050 - Smart Module Networking Scenario; Independent Networking Scenario; CAN Teamwork + RS485 Monitoring

Figure 4-89 RS485 monitoring communications cable
(4) Blue (5) White-and-blue
----End
4.9.8.2 Smart Module Networking Scenario
NO TE
Smart module networking is the networking of in-row smart cooling products using the
ECC800 in a smart module.
Step 1 Connect teamwork and monitoring communications cables.
Networking
Teamwork Monitoring
Protocol MAC_CAN Modbus-TCP
Figure 4-90 Connecting communications cables
----End
4.9.8.3 Independent Networking Scenario
NO TE
Select one of the following networking modes according to the actual situation.
4.9.8.3.1 CAN Teamwork + RS485 Monitoring
NetCol5000-A050 In-row Air Cooled Smart Cooling
Product
User Manual 4 Installation
Issue 08 (2021-09-17) Copyright © Huawei Technologies Co., Ltd. 112
