Item Description
Mounting ear 19-inch supported
Weight 2.3 kg
Insertion loss ≤ 0.75 db
Return loss Single-mode: ≥ 30 db
Operating temperature –40°C to +65°C
Storage temperature –40°C to +70°C
Relative operating humidity ● Long term: 5% RH to 85% RH, non-
condensing
● Short term: 5% RH to 95% RH,
non-condensing
Relative storage humidity 0% RH to 95% RH, non-condensing
Table 3-257 Optical modules, jumpers, and ports supported by the 10-Port-
MPO-12-40-Port-LC-Breakout Box (single-mode)
Optical Module
MPO-MPO Fiber Port
[02311NUA/
OSM010N11] Function
Module,OSM010N11,Hig
h Speed Transceiver,QSFP
+,
1310,41.25Gbps,-8.2dBm,
0.5dBm,-12.6dBm,MPO,S
M,10km
[14134759/MPO12-
MPO12-SM-10] Optical
Cable Parts,MPO/
APC,MPO/APC,Single
mode,10m,8
cores,GJFH-8G.
657A2,3.5mm,LSZH,
43mm Short
MPO,Bending insensitive
Supported boards:
Check the
Hardware
Description
. If the
description of a port
contains QSFP28 or QSFP
+ and and supports the
breakout function, the
optical module and
breakout
ber can be
used together with the
port.
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 345
