● Contents in the cells should be aligned in the center. In a single-line printout,
the dividing lines and the word "TO:" should not be covered by printed
characters.
● When the cells are merged and the printouts are made in multiple lines, avoid
covering the word "TO:" when printing the text. Use the space bar to move
the text to the next line.
Writing Labels
Writing Tools
To make sure the printouts are clear and legible, use black markers instead of
ball-point pens to write the labels.
If no marker is available, black ball-point pens are allowed, although not
recommended. Compared with ball-point pens, waterproof markers are better.
When writing with a ball-point pen, do not leave the oil on the label, which may
contaminate the label and blur the words.
The delivered marker has two nibs. Use the smaller nib to write the labels.
Font
For the sake of legibility, use standard block letters and numbers as shown in
Table 4-39.
Table 4-39 Standard typeface for handwriting
0
1 2 3 4 5 6 7 8
9 A B C D E F G H
I J K L M N O P Q
R S T U V W X Y Z
Determine the size of characters based on the number of letters or digits and
ensure that the characters are distinct and tidy.
Placement of text on a label is shown in Figure 4-174.
Figure 4-174 Placement of text on a label
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 507
