Figure 4-208 Leveling the cabinet
The ground anchors can be adjusted from 0 mm to 10 mm in height.
----End
(Optional) Combining Cabinets
Context
This section applies to installation of two or more cabinets.
After settling and leveling two adjacent cabinets, combine the cabinets with
combination plates.
Combine one cabinet with one adjacent cabinet at a time.
Procedure
Step 1 Use a Phillips screwdriver to remove the screws from combination plates on the
front and rear doors. See callout 1 in Figure 4-209.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 548
