Each combination plate is secured with one screw on the cabinet. To combine two cabinets,
remove the screws from the posts of one cabinet. These removed screws will be used to
secure the combination plate.
Step 2 Put a combination plate through a notch on the door, and then secure the
combination plate with screws removed in step 1. See callout 2 in Figure 4-209.
Step 3 Callout 3 in Figure 4-209 shows the combination plate after the cabinets are
combined.
Figure 4-209 Combining cabinets
