● On a cabinet at the middle of a row, there are four points for cabinet combination at
both the front door and rear door.
● On a cabinet at the end of a row, there are two points for cabinet combination at both
the front door and rear door.
● The height
dierence and distance between cabinets cannot exceed 3 mm after
cabinets are combined.
----End
Securing the Cabinet
Procedure
Step 1 Verify that the spring washers, at washers, and installation covering have been
correctly installed on the expansion bolts.
Step 2 Secure four expansion bolts on diagonal lines using a torque socket, with a torque
of 45 N•m. See Figure 4-210.
Figure 4-210 Securing the cabinet
----End
