● Strip 18–23 mm o the outer jacket from the end.
● Ensure that the wires do not split during cable stripping.
Cables applicable to dual-DC connectors shall have a cross-sectional area of 16–25
mm
2
.
Figure 4-301 Trimming power cables
2. Rotate the cover plate until the screws are completely exposed, as shown in
the following
gure.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 662
