Applicable Ranges

The labels can be applied to Ethernet cables.

Label Content

Table 4-86 shows the information on both sides of the labels axed to Ethernet

cables.

You can also decide the label content based on the actual environment. If the

device is not installed in the cabinet, for example, you can remove the cabinet

number.

Table 4-86 Information on the Ethernet cables

Content Meaning Example

MN-B-C-D MN: cabinet

number

For example, A01 is the rst cabinet in row A.

B: chassis

number

Numbered in bottom-up order with two

digits, for example, 01.

C: physical slot

number

Numbered with two digits in top-down and

left-right order. For example, 01.

D: network port

number

Numbered in top-down and left-right orders.

For example, 01.

MN-Z MN: cabinet

number

For example, B02 is the second cabinet in

row B.

Z: Location

number

Fill in the location number of the terminal

device on site. If the cable is connected to a

device in a cabinet, specify the serial

numbers of the cabinet, the chassis, and the

Ethernet interface of the device. For example,

B02-03-12. If the cable is connected to the

Network Management Station (NMS),

specify the

specic location of the NMS.

The contents of the labels for network cables connecting hubs and devices or

agents and the network cables for other purposes should be

specied according to

actual connections. The details are as follows:

● For a network cable connecting a hub and device, the label on the hub end

should indicate the numbers of the chassis and cabinet where the hub resides,

and the serial number on the hub. The label on the device end should indicate

the number of the chassis and cabinet where the device is located. If the

device is a standalone device, provide the

specic position of the device.

● For a network cable connecting a hub and an agent or terminal, the label on

the agent or terminal end should contain the serial number of the network

interface. The

denitions of the cabinet number and chassis number are the

same as those described in Table 1-28.

HUAWEI NetEngine 8000 F

Hardware Guide 4 Hardware Installation and Parts Replacement
