Huawei UPS2000-H - Lead-Acid Battery Pack

Optional
Component
Model Function Remarks
4G module iIOT-WAC0411 Reports alarms and signals to the
network management device
(cloud NMS) in wireless mode.
Used together with an
SNMP card.
iIOT-WAC0412 ● European standards
or LTE FDD:
B1/B2/B3/B4/B5/B7/
B8/B20
● DC-HSPA+/HSPA+/
HSPA/UMTS:
850/900/1900/2100
MHz
● GSM/GPRS/EDGE:
850/900/1800/1900
MHz
● Used together with
an SNMP card.
PDU PDC-0091V2ACIOA Controls and protects input and
output power ow, increases
output sockets, and distributes
input and output power of the
1+1 parallel systems.
-
Parallel cable - Connects UPSs in parallel. A parallel cable is 1.5
meters long.
PDU parallel
power cable
- Serves as the input and output
power cables for a parallel UPS
system.
-
rPDU PDU2000-16-1PH-8
/0-B1
A professional cabinet-level
power distribution unit. It can be
widely used in various network
cabinets and server cabinets to
provide stable and reliable power
distribution for IT devices in the
cabinets.
-
PDU2000-63-1PH-1
6/8-B1
PG
connection
box
- Used to provide cable inlets and
outlets and secure the cables.
-
2.6.2 Lead-Acid Battery Pack
A battery pack consists of 20 built-in 12 V, 7 Ah/9 Ah VRLA batteries connected in
series and is congured for the 6 kVA and 10 kVA UPSs. A maximum of four
battery packs can be connected in parallel.
