Husky Altanium Matrix5 User Manual

v 1.0 — February 2020 Altanium Matrix5
170 Data Collection Stop Conditions
Table 12-5 Cycle Mode - Conditions to Stop (UltraSync-E or Altanium Servo Control Installed)
Heats Running
Condition
Enabled
UltraSync-E
Engaged
Condition
Enabled
Mold Servo
Controller
Engaged
Condition
Enabled
Cycle Mode
Conditions
Selection Shown
on Screen
Conditions to Stop
Yes Yes No Yes If pair of digital inputs (start and end)
• End digital input does not go high before the
cycle time limit has expired
• Heats are turned off or not At Temperature
• UltraSync-E is disengaged or disabled
System changes to timed data collection
If one digital input to start and timer to end data
collection:
• Start digital input is not high again before the
cycle time limit has expired
• Heats are turned off or not At Temperature
• UltraSync-E is disengaged or disabled
System changes to timed data collection
If one digital input to start and end data collection:
• Start digital input does not go high again
before the cycle time limit has expired
• Heats are turned off or not At Temperature
• UltraSync-E is disengaged or disabled
System changes to timed data collection
