v 1.0 — February 2020 Altanium Matrix5
174 Cycle Input (Heat Control Only)
12.4.3.3 Cycle Input (Heat Control Only)
Cycle Input supplies a start or end of cycle signal from the injection molding machine. This
input can be configured as the trigger to log process data on Altanium systems configured
for heats control only.
When this input is selected for use, the controller looks for a rising edge to trigger the start or
end of a cycle.
NOTE: This should be connected to a cyclical signal (the signal goes HIGH to LOW during
each injection cycle)
This feature can be enabled or disabled when you select or deselect the 'In Use' check-box in
the Cycle Input line on the Heats Page 1 tab of the Digital Inputs screen. Refer to
Section 13.1.3.
No Yes Yes Yes If pair of digital inputs (start and end):
• End digital input does not go high before the
cycle time limit has expired
• UltraSync-E is disengaged or disabled
• Mold Servo Controller is disengaged or
disabled
System does not change to timed data collection
If one digital input to start and timer to end data
acquisition:
• Start digital input is not high again before the
cycle time limit has expired
• UltraSync-E is disengaged or disabled
• Mold Servo Controller is disengaged or
disabled
System does not change to timed data collection
If one digital input to start and end data
acquisition:
• Start digital input does not go high again
before the cycle time limit has expired
• UltraSync-E is disengaged or disabled
• Mold Servo Controller is disengaged or
disabled
System does not change to timed data collection
Yes No No Yes Not applicable
Table 12-5 Cycle Mode - Conditions to Stop (UltraSync-E or Altanium Servo Control Installed) (Continued)
Heats Running
Condition
Enabled
UltraSync-E
Engaged
Condition
Enabled
Mold Servo
Controller
Engaged
Condition
Enabled
Cycle Mode
Conditions
Selection Shown
on Screen
Conditions to Stop
