Test Results Screen Values 87
User Guide v 1.0 — February 2020 Mold Diagnostics
The buttons and fields on the Test Results screen are described in Table 8-2.
8.2.1 Test Results Screen Values
The test result columns are described in Table 8-3.
Table 8-2 Test Results Screen Buttons and Fields
Item Description
Mold Diagnostics Opens the Mold Diagnostics screen.
Rewire Automatically reassigns all the sensors to their correct location with the
use of the test results.
Test Results Opens the Test Results screen from the Cross-Talk and Temperature
Graphs screens.
Cross-Talk Opens the Cross Talk screen.
Temperature Graphs Opens the Temperature Graphs screen.
Start Time The time the test was started.
Elapsed Time The elapsed time of completed test.
Table 8-3 Test Result Columns
Item Description
Zone Shows the zone number.
Name Shows the zone name.
Sen. Identifies the number of the sensor that is used for that zone.
Fuses The fuses test shows if the fuse for that zone operates correctly. The fuse
values are shown as follows:
• Question Mark: the fuse test for the zone was not done.
• Check Mark: shows the fuse for the zone completed the test
satisfactorily.
• X: shows a failure of the fuse test for the zone.
T/C The thermocouple test shows if the thermocouple for that zone operates
correctly. The thermocouple values are shown as follows:
• Question Mark: shows the thermocouple test for the zone was not
done.
• Check Mark: shows the thermocouple for the zone completed the
test satisfactorily.
• X: shows a failure of the thermocouple test for the zone, because it
was reversed or lost.
Amp Current drawn by the heater during the test for each zone.
VAC Line voltage reading during the test for each zone.
