Husky Altanium Matrix5 User Manual

v 1.0 — February 2020 Altanium Matrix5
188 Remote Load Base Connector ID
Remote Load / D BLK/WHT Setup B2
Remote Load / E BLU Setup B3
Remote Load / F BLU/WHT Setup B4
Remote Load / G BLU/BLK Setup B5
Remote Load / H GRN 12 V+
Remote Load / J GRN/BLK 12 V+
Remote Load / K GRN/WHT 0 V
Remote Load / L ORG 0 V
Remote Load / M ORG/BLK Remote file loaded
Remote Load / N RED Remote file loaded
Table 13-10 Remote Load Base Connector Pins (Continued)
Connector/Pin Field Cable Wire Color Signal Function
