Hypertherm HyPerformance Plasma HPR400 User Manual

OperatiOn
4-34 HPR400XD Auto Gas – 806160
Estimated kerf-width compensation
The widths in the chart below are for reference. Differences between installations and material composition may cause
actual results to vary from those shown in the table. N/A = data not available.
Metric
Process
Thickness (mm)
1.5 3 5 6 8 10 12 15 20 25 30 32 38 40 50 60 70 80
Mild steel
400A O
2
/ Air N/A N/A N/A N/A N/A N/A 3.40 3.50 3.68 3.76 4.06 N/A N/A 4.88 5.94 6.60 7.80 9.10
260A O
2
/ Air N/A N/A N/A 2.54 2.54 2.54 2.79 3.43 3.56 3.91 N/A 4.32 4.45 N/A 5.72 N/A N/A N/A
200A O
2
/ Air N/A N/A 1.93 1.98 2.09 2.20 2.26 2.61 2.95 3.16 N/A 4.19 4.87 N/A 5.45 N/A N/A N/A
130A O
2
/ Air N/A 1.64 1.77 1.81 1.92 2.04 2.11 2.22 2.65 3.43 N/A 4.26 4.59 N/A N/A N/A N/A N/A
80A O
2
/ Air N/A 1.37 1.53 1.73 1.79 1.91 2.00 2.11 2.72 N/A N/A N/A N/A N/A N/A N/A N/A N/A
50A O
2
/ O
2
1.52 1.74 1.86 1.86 2.09 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
30A O
2
/ O
2
1.35 1.45 1.54 1.56 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Stainless steel
400A N
2
/ Air N/A N/A N/A N/A N/A N/A 3.00 2.90 2.80 3.10 3.30 N/A N/A 5.00 N/A N/A N/A N/A
400A H35 / N
2
N/A N/A N/A N/A N/A N/A N/A N/A 5.10 5.30 5.45 N/A N/A 5.50 5.80 6.35 N/A N/A
400A
H35 and N
2
/ N
2
N/A N/A N/A N/A N/A N/A 3.90 4.00 4.20 4.45 4.65 N/A N/A 5.15 5.65 5.90 6.35 6.95
260A
H35 and N
2
/ N
2
N/A N/A N/A 2.34 3.02 3.71 3.80 3.82 4.32 4.34 N/A 4.58 4.77 N/A 5.63 N/A N/A N/A
260A N
2
/ Air N/A N/A N/A 2.31 2.39 2.46 2.54 2.76 3.08 3.30 N/A 3.64 4.43 N/A 4.16 N/A N/A N/A
260A H35 / N
2
N/A N/A N/A N/A 3.84 3.83 3.81 3.81 4.06 4.32 N/A 4.53 4.70 N/A 7.46 N/A N/A N/A
200A N
2
/ N
2
N/A N/A N/A N/A 2.10 2.16 2.29 2.47 2.92 N/A N/A N/A N/A N/A N/A N/A N/A N/A
200A H35 / N
2
N/A N/A N/A N/A 3.66 3.68 3.81 3.68 3.94 N/A N/A N/A N/A N/A N/A N/A N/A N/A
200A
H35 and N
2
/ N
2
N/A N/A N/A N/A 3.05 3.05 3.05 2.88 3.30 N/A N/A N/A N/A N/A N/A N/A N/A N/A
130A H35 / N
2
N/A N/A N/A N/A 2.69 2.72 2.77 3.03 2.90 3.25 N/A N/A N/A N/A N/A N/A N/A N/A
130A N
2
/ N
2
N/A N/A N/A 1.83 1.89 1.88 2.42 2.51 3.00 N/A N/A N/A N/A N/A N/A N/A N/A N/A
130A
H35 and N
2
/ N
2
N/A N/A N/A 1.78 2.25 2.73 2.76 3.03 2.90 N/A N/A N/A N/A N/A N/A N/A N/A N/A
80A F5 / N
2
N/A N/A 1.02 1.20 1.05 0.96 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
45A F5 / N
2
0.59 0.38 0.52 0.54 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
45A N
2
/ N
2
0.49 0.23 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
