Hypertherm HyPerformance Plasma HPR400 User Manual

Appendix B – CnC interfACe protoCol
b-6 HPR400XD Auto Gas – 806160
Command table (1 of 14)
ID Command System Description
000 HELLO Manual gas system
Auto gas system
Establish communications with the plasma system. Use this command
to determine if the system is configured as an 800XD or 400XD. This
command will return “HPR800XD” in place of “HPR400XD” when the
secondary power supply is connected and the power is on.
Data:
None
Return value:
String identifying the system
Sample:
>00090<
>000HYPERFORMANCE130MANUALB5<
or
>000HYPERFORMANCE130AUTO30<
or
>000HYPERFORMANCE130AUTOMIX1E<
001 VERSION Manual gas system
Auto gas system
Get the version of the power supply firmware.
Data:
None
Return value:
Power supply firmware then Gas console firmware, space-delimited
Sample:
>00191<
>001A.0 A.25< (power supply rev A, gas rev A)
002 GET_STATE Manual gas system
Auto gas system
Get the current state of the plasma system.
Data:
None
Return value:
Status code (see table V)
Sample:
>00292<
>002000052< (status code 0)
003 LAST_ERROR Manual gas system
Auto gas system
Get the last error that occurred at the system.
Data:
None
Return value:
Error code (see table IV)
Sample:
>00393<
>00301165B< (error code 116)
004 REMOTE_MODE Manual gas system
Auto gas system
Switch system into remote mode, to allow remote control of the plasma
system.
Data:
None
Return value:
1 = accepted, 0 = not accepted
Sample:
>00494<
>0041C5<

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
