Hypertherm HyPerformance Plasma HPR400 User Manual

SpecificationS
2-6 HPR400XD Auto Gas – 806160
Cooler – 078531
• Thecoolingsystemcancontainupto34.5liters(9gallons)ofcoolant.
• Maximumcablelengthfromthecoolertothepowersupplyis4.57meters(15ft).
• Maximumhoselengthfromthecoolertotheignitionconsoleis76.2meters(250ft).
• Allow 1 m (3 ft) of space on all sides of the cooler for ventilation and service.
457 mm
18.00”
895 mm
35.25”
895 mm
35.25”
622 mm
24.50”
76 mm
3.00”
To the filter on
the rear of the
cooler
Weight with no
coolant
75 kg
165 lb

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
