Hypertherm HyPerformance Plasma HPR400 User Manual

Appendix B – CnC interfACe protoCol
b-10 HPR400XD Auto Gas – 806160
Command table (5 of 14)
ID Command System Description
079 GET_PS_INFO Manual gas system
Auto gas system
Returns pressures, system state, and system error,
space-delimited
Data:
None
Return value:
Plasma cutflow pressure (0044 = 44 psi)
Plasma preflow pressure (0044 = 44 psi)
Shield cutflow pressure (0044 = 44 psi)
Shield preflow pressure (0044 = 44 psi)
Current setpoint (amps)
System state (see table V) (0003 = state 3)
System error (see table IV) (0000 = error 0)
Cut gas 1 pressure (0044 = 44 psi)
Cut gas 2 pressure (0044 = 44 psi)
N
2
Mix inlet pressure (0044 = 44 psi)
Gas2 Mix inlet pressure (0044 = 44 psi)
Note: Cut gas 1, Cut gas 2, N
2
mix inlet, and Gas 2 mix inlet are
not measured in the manual gas console configuration.
Sample:
>079A0<
>079PC0044 PP0042 SC0034 SP0035 CS0040 ST0003
ER0000 CG0000 CG0000 MV0000 MV0000DE<
084 DOWNLOAD_SOFTWARE
Not currently implemented on the
HD4070 or the HPR systems
TBD Download new firmware to the plasma system.
Data:
TBD
Return value:
1 = packet accepted, 0 = not accepted
Sample:
TBD
085 WAKE Manual gas system
Auto gas system
This command is used to wake a system and enable its
transmitter to communicate on a multi drop line.
Data:
System ID, which is set by dipswitches on PC board.
Return value:
Echo of the command
Sample:
>0850CD<
>0850CD<
086 SLEEP Manual gas system
Auto gas system
Tell all systems on the line to disconnect their transmitters
Data:
None
Return value:
None
Sample:
>0869E<
No response

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
