Hypertherm HyPerformance Plasma HPR400 User Manual

Appendix B – CnC interfACe protoCol
b-12 HPR400XD Auto Gas – 806160
Command table (7 of 14)
ID Command System Description
096 SET_INLET_GASES Auto gas system Set inlet gases for auto console. If inlet gases change, the
power supply will enter the purge state. Gas type changes
are not allowed when the system is cutting (state 4 – state
10).
Data:
Plasma gas type code (See table VI),
Shield gas type code (See table VI),
space-delimited.
Return value:
1= accepted, 0 = not accepted
Sample:
>0961 626< (Set plasma gas = O
2
and set shield gas = N
2
)
>0961D0<
097 READ_CORNER_CURRENT Manual gas system
Auto gas system
Read the corner-current percentage
Data:
None
Return value:
Percentage
Sample:
>097A0<
>09700756C< (75%)
098 GET_INLET_GASES Manual gas system
Auto gas system
Read the inlet gas types
Data:
None
Return value:
Plasma gas type code (See table VI),
Shield gas type code (See table VI),
space-delimited
Sample:
>098A1<
>0980001 000648< (Plasma gas = O
2
and shield gas = N
2
)
099 GET_GAS_FLOWS Auto gas system Read the gas setpoints
Data:
None
Return value:
Plasma cutflow setpoint (psi),
Plasma preflow setpoint (psi),
Shield cutflow setpoint (psi),
Shield preflow setpoint (psi),
N
2
Mix setpoint (psi),
Gas 2 mix setpoint (psi)
space-delimited.
(55 = 55 psi)
Sample:
>099A2<
>0990055 0045 0035 0025 0050 0050EE<

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
