Hypertherm HyPerformance Plasma HPR400 User Manual

HPR400XD Auto Gas – 806160 c-1
Appendix C
ROBOTIC APPLICATIONS
In this section:
Components for robotic applications ....................................................................................................................................................c-2
Torch leads .......................................................................................................................................................................................c-2
Ohmic contact extension ...............................................................................................................................................................c-2
Rotational mounting sleeve (optional) – 220864 ..................................................................................................................c-3
Leather overwrap – 024866 .......................................................................................................................................................c-3
Robotic teaching torch (laser pointer) – 228394..................................................................................................................c-3
Torch and rotational mounting sleeve dimensions...................................................................................................................c-3
Rotational mounting sleeve clamp dimensions.........................................................................................................................c-4

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
