IAI MSEL User Manual

Chapter 5 I/O Parameter
111
I/O Parameters
No. Parameter name
Default value
(Reference)
Input range Unit Remarks
351
Vision system I/F 1 function
selection 1
(For PC/PG/PCF/PGF type)
3105500H 0H ~ FFFFFFFFH
* PCX/PGX is system reservation
Bits 0 to 3: Function select
(0: Not in use, 1: Use)
Bits 4 to 7: Communication device selection
( 0: System reservation,
1: System reservation,
2: Ethernet Ch31,
3: Ethernet Ch32,
4: Ethernet Ch33,
5: Ethernet Ch34)
(Related I/O Parameters No.124,129 to
143,145 to 148)
Bits 8 to 11: Vision system I/F 1 response timeout value
(sec)
Bits 12 to 19: Vision system I/F 1 capturing command
disable delay timer value (msec)
Bits 20 to 23: Vision system I/F 1 capturing delay prediction
timer value (msec)
Bits 24 to 31: Number of vision system I/F 1 capturing
command retries * No retry if 0
352
Vision system I/F 1 function
selection 2
(For PC/PG/PCF/PGF type)
0H 0H ~ FFFFFFFFH
* PCX/PGX is system reservation
Bits 0 to 7: Vision system I/F 1 communication format
select
( 0: COGNEX,
1: System reservation,
2: Keyence)
(Related I/O Parameter No.353)
Bits 8 to 31: System reservation
353
Vision system I/F 1 function
selection 3
(For PC/PG/PCF/PGF type)
54313C0DH 0H ~ FFFFFFFFH
* PCX/PGX is system reservation
Bits 0 to 7: Vision system I/F 1 communication delimiter
Bits 8 to 15: Vision system I/F 1 communication header 1
* No header when 0
Bits 16 to 31: Vision system I/F 1 communication header 2
* No header when 0
354 System reservation 0
355 System reservation 0
356
Vision system I/F 1 initializing
complete status physical input
port number
(For PC/PG/PCF/PGF type)
0 0 ~ 299
* PCX/PGX is system reservation
* Invalid if “0” is set
357
Vision system I/F 1
Image-capture command
physical output number
(For PC/PG/PCF/PGF type)
0 0 ~ 599
* PCX/PGX is system reservation
358 (For extention) 0
359 (For extention) 0
360 (For extention) 0
361 (For extention) 0
362 (For extention) 0
363 (For extention) 0
364 (For extention) 0
365 (For extention) 0
366 (For extention) 0
367 (For extention) 0
368 (For extention) 0
369 (For extention) 0
370 (For extention) 0
371 (For extention) 0
372 (For extention) 0
373 (For extention) 0
374 (For extention) 0
375 (For extention) 0
376 (For extention) 0
378 (For extention) 0
379 (For extention) 0
380 (For extention) 0
381 (For extention) 0
382 (For extention) 0
383 (For extention) 0
384 (For extention) 0
385 (For extention) 0
386 (For extention) 0
387 (For extention) 0
