The Status Bar
107
Adjust the Origin
Figure 86. Adjusting the Origin
By default the origin of the graph is located at the first sample of the captured
data (leftmost position). You can adjust the origin by clicking on the ruler and
dragging the origin to the desired location. See Figure 86.
You can use this to determine the length/slippage of scanned labels in
conjunction with the crosshair.
The Status Bar
The status bar is at the bottom of the Media Profiler window (see Figure 79 on
page 100) and is divided into five sections. The first section displays status
messages. The second section displays the first line of the notes, if notes
were added (see Notes on page 101). The last three sections display the
model, version, and part number from the printer being profiled. By default
these are set to N/A.
For More Information
Refer to “Running Media Profile” in the
User’s Manual
.
