Input/Output Fields
153
Input/Output Fields
Figure 132. CST Input/Output Fields
These fields allow you to select the appropriate Input/Output sequence.
Use Shift + Alt + i and Shift + Alt + o to switch between the Input and Output
fields.
See “Modes And Attributes” on page 155
for the different Mode selections.
Use the four buttons on the right with the Input/Output fields.
New: Clears the Input and Output fields.
Append: Enters the Input and Output fields at the end of the current CST.
Insert: Enters the Input and Output fields before the selected entry in the
CST.
Update: Re-enters the Input and Output fields into the current CST after
editing.
Input Field
The Input Field displays the Input string the datastream adapter looks for.
Enter Input strings in one of two ways: as an ASCII character or as a hex
value. You can switch between the two entry modes by using the up and
down arrow keys. To select attributes, place the mouse over a character and
right-click. Available attributes display (see “Modes And Attributes” on
page 155).
Output Field
Use the Output Field to specify what the datastream adapter does when the
incoming data matches the data and conditions specified in the Input Field.
Specify data if performing a Replace, or specify the name of a CST if
performing a CST Select.
NOTE: Attributes are not available in the Output field.
