Job Capture Features
119
Search Captured Data
You can search captured data for specific sequences. Select Search
Search Captured Data. Enter the data as a hex or text string. Click OK, and
the matching data highlights.
To further refine your search, you can choose whether or not to ignore the
case, and specify the direction and origin of the search. If you have text
selected, you can also choose whether to search the selected text or all text
(Global). Use the down arrow in the upper-right corner to see a history of your
searches. See Figure 97.
Search Again
To continue searching, click Search Again. A message appears if the search
is unsuccessful.
View
Display Format
Data displays in three ways:
• Text
• Hex
• Capstone
Capstone is for Coax/Twinax applications. You can edit Capstone data in Hex
mode only.
Display Command Codes
• Normal: Codes do not display.
• Dots: Dots represent the code.
• Mnemonics: Codes display within brackets. For example, Line Feed is
<LF>, Carriage Return is <CR>, etc.
Capture
Start
Starts the capture. You can also use the (start capture) button.
Stop
Stops the capture. You can also use the (stop capture) button.
Data From
Selects the capture source of data. Options include:
• Parallel/E-Net Adapter In
• Serial In
• Serial Out
