14
Chapter 1 Printer Setup
Set Telemetry Path (6700/4400 Series Only)
The following procedure enables you to collect data using the Data Validation
application.
1. On the operator panel, press the PAUSE key to take the printer offline.
2. Press to place the printer in Menu mode. QUICK SETUP displays on
the operator panel.
3. Press ↓ and
↵ at the same time to unlock the ↵ key.
4. Press + until VALIDATOR displays.
5. Press ↓ until Telemetry Path displays.
6. Press + or – until Network Port displays.
7. Press
↵ to activate it.
NOTE: Since only one port can be used at a time, DEACTIVATING HOST
SERIAL displays.
If you later change the setting to Serial Port or Disabled,
REACTIVATING HOST SERIAL will display.
8. Press ↓ and
↵ at the same time to lock the ↵ key.
9. Press PAUSE twice to put the printer back online.
For more information, refer to the
Online Data Validator User’s Manual
.
Check Port Number
Make sure your printer port number has the same setting as the Ethernet
Interface.
To check the port number using the PMU, see page 20.
To check the port number on the printer, see Table 1 to determine the port
number menu location for your printer model. The default port number is
3001.
IMPORTANT
Do not set the Port Number to the same value as the Status Port Number
(the default is 3002) or the Mgmt Port Number (the default is 3007).
.
.
.
Table 1. Port Number Menu Location
Printer Model Menu
6700-M40 Series INTERFACES
Printer Mgmt
PNE Port Number
6700 Series PRINTER MGMT or Factory
PNE Port Number
4400 Series Factory
PMU Port Number
6500 Series PRINTER MGMT
PRINTER MANAGER PORT NO.
6400 Series SERVICE
PRINTER MGMT
PRINTER MANAGER PORT NO.
