Chapter 3 Operator Panel
Operator Panel
The PMU includes a virtual operator panel that simulates all the functions of
the physical operator panel on your printer. See Table 5 below which lists the
different virtual operator panels.
The layout of the operator panel changes to visually simulate the printer being
used (line matrix or thermal), but the keys and indicators function as
described on page 111, regardless of the type of printer used.
The virtual operator panel uploads special font tables from the printer and
uses them to match the printer’s actual front panel display. If viewing Asian
language symbols, the virtual operator panel determines and displays the
proper number of lines.
To access the operator panel, select the appropriate printer from the printer
database and then select Applications
 Operator Panel or click the
(operator panel) button.
Table 5. Virtual Operator Panels
Figure Page Printer
Figure 87 page 109 6500 Series line matrix
Figure 88 page 109 6400 Series line matrix
Figure 89 page 110 6700/4400 Series thermal
Figure 90 page 110 6700-M40 Series thermal
