Table 13. IMM2 error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
806f060d-0400xxxx
806f060d-0401xxxx
806f060d-0402xxxx
806f060d-0403xxxx
806f060d-0404xxxx
806f060d-0405xxxx
806f060d-0406xxxx
806f060d-0407xxxx
Array %1 has failed.
(%1 =
CIM_ComputerSystem.
ElementName)
Error An array is in a
failed state. (Sensor
= Drive n Status)
(n = hard disk
drive number)
1. Make sure that the RAID adapter
firmware and hard disk drive
firmware is at the latest level.
2. Make sure that the SAS cable is
connected correctly.
3. Replace the SAS cable.
4. Replace the RAID adapter.
5. Replace the hard disk drive that is
indicated by a lit status LED.
806f070d-0400xxxx
806f070d-0401xxxx
806f070d-0402xxxx
806f070d-0403xxxx
806f070d-0404xxxx
806f070d-0405xxxx
806f070d-0406xxxx
806f070d-0407xxxx
The Drive n Status
rebuilt has been in
progress. (n = hard
disk drive number)
Info The Drive n has
rebuilt in progress.
(n = hard disk
drive number)
No action; information only.
PCI messages
806f0021-3001xxxx PCI fault has been
detected for PCI n.
(n = PCI slot
number)
Error A PCI fault has
been detected.
1. Check the PCI LED. See more
information about the PCI LED in
“Light path diagnostics LEDs” on
page 109.
2. Reseat the affected adapters and
riser card.
3. Update the server firmware (UEFI
and IMM) and adapter firmware.
Important: Some cluster solutions
require specific code levels or
coordinated code updates. If the
device is part of a cluster solution,
verify that the latest level of code is
supported for the cluster solution
before you update the code.
4. Remove both adapters.
5. Replace the riser cards.
6. (Trained technicians only) Replace
the system board (see “Removing
the system board” on page 354 and
“Replacing the system board” on
page 359).
Chapter 4. Troubleshooting 165
