Figure 55. Open I/O station seen from the left

Bulk loading magazines

1. Unlock the magazine by pressing the magazine button for more than 3 seconds, wait for the button to

flash fast and then pull out the magazine.

a. From the Operator Panel or Management GUI, select the module and then select Open Magazine.

You can also press the release button on the front panel of the module to release the magazine.

b. Wait until the magazine is unlocked, and then pull out the magazine.

Note: Wait for the Operator Panel/Management GUI message to say the magazine is unlocked

before the magazine is pulled out.

Figure 56. Magazine pulled out

2. Load the tape cartridges into the magazine.

IBM Condential

70IBM TS4300 Tape Library Machine Type 3555: User's Guide
