IBM TS4300

Figure 15. Half-height SAS dual port
Table 9. Half-height SAS dual port
Number Description
1 SAS port 0
2 SAS port 1
3 Drive sled indicators
Figure 16. Half-height FC single port
Table 10. Half-height FC single port
Number Description
1 FC port 0
2 Drive sled indicators
IBM Condential
Chapter 1. Overview15
