Figure 13. Mixed drives in a logical library
Drive sled back panels
Indicator LEDs are included on all drive sled back panels.
Six indicator LEDs are included on all drive sleds as shown.
Figure 14. Drive sled indicators
Table 8. Drive sled indicators
Number Description
1 Port 0 activity
2 Port 1 activity
3 Library communication
4 Cartridge present
5 Power
6 Beacon /UID
IBM Condential
14IBM TS4300 Tape Library Machine Type 3555: User's Guide
