Figure 22. F
ront bezel height
Figure 23. Depth from front o
f the bezel to back o
f the fan on an inserted drive sled
Electrical
speciîš´cations
f
or one module (base or expansion)
T
able 24. Electrical
speciîš´cations
for one module (base or expansion)
Characteris
tic
Speciîš´cation
Maximum current
3.7 A
V
oltage
100 - 240 V 50/60 Hz
Maximum power consumption
370 W
IBM
Conîš´dential
Chapter 2. Planning
35
66
