The following table lists the part numbers for the server replaceable components.
Table 30. Parts listing, 4U server model with non-hot-swap power supplies
Index
number Description of server component
CRU part
number (Tier 1)
CRU part
number (Tier 2)
2 Power supply, 300W, fixed 00AL206
2 Power supply, 350W, fixed 00AL205
3 System board 46W9038
4 Memory, 4 GB 2Rx8 UDIMM, 1600 MHz, DDR3 00D5014
4 Memory, 8 GB 2Rx8 UDIMM, 1600 MHz, DDR3 00D5018
5 System fan, rear 00AL089
6 Heat sink 00Y8238
7 Microprocessor, Intel Core-i3 4360, 3.7 GHz, 4 MB, 1600 MHz, 54 W
(2-core)
00KA424
7 Microprocessor, Intel Core-i3 4350, 3.6 GHz, 4 MB, 1600 MHz, 54 W
(2-core)
00KA425
7 Microprocessor, Intel Core-i3 4150, 3.5 GHz, 3 MB, 1600 MHz, 54 W
(2-core)
00KA427
7 Microprocessor, Intel Core-i3 4150T, 3.0 GHz, 3 MB, 1600 MHz, 35 W
(2-core)
00KA428
7 Microprocessor, Intel Pentium G3450, 3.4 GHz, 3 MB, 1600 MHz, 54
W (2-core)
00KA429
7 Microprocessor, Intel Pentium G3240, 3.1 GHz, 3 MB, 1600 MHz, 54
W (2-core)
00KA431
7 Microprocessor, Intel Pentium G3240T, 2.7 GHz, 3 MB, 1600 MHz, 35
W (2-core)
00KA432
7 Microprocessor, Intel Celeron G1840, 2.8 GHz, 2 MB, 1600 MHz, 54
W (2-core)
00KA434
7 Microprocessor, Intel Pentium G3440, 3.3 GHz, 3 MB, 1600 MHz, 54
W (2-core)
00KA450
9
1
3
7
6
2
4
10
5
12
11
8
13
14
Figure 76. Server components for 4U server model with non-hot-swap power supplies
166 System x3100 M5 Type 5457: Installation and Service Guide
