IBM x3100 M5 Type 5457 User Manual

Table 30. Parts listing, 4U server model with non-hot-swap power supplies (continued)
Index
number Description of server component
CRU part
number (Tier 1)
CRU part
number (Tier 2)
7 Microprocessor, Intel Xeon E3-1231 v3, 3.4 GHz, 8 MB, 1600 MHz, 80
W (4-core)
00KA451
7 Microprocessor, Intel Xeon E3-1241 v3, 3.5 GHz, 8 MB, 1600 MHz, 80
W (4-core)
00KA452
7 Microprocessor, Intel Xeon E3-1271 v3, 3.6 GHz, 8 MB, 1600 MHz, 80
W (4-core)
00KA453
7 Microprocessor, Intel Xeon E3-1281 v3, 3.7 GHz, 8 MB, 1600 MHz, 95
W (4-core)
00KA454
7 Microprocessor, Intel Xeon E3-1275L v3, 2.7 GHz, 8 MB, 1600 MHz,
45 W (4-core)
00KA455
7 Microprocessor, Intel Xeon E3-1240L v3, 2.0 GHz, 8 MB, 1600 MHz,
25 W (4-core)
00KA456
7 Microprocessor, Intel Xeon E3-1220 v3, 3.1 GHz, 8 MB, 1600 MHz, 80
W (4-core)
00Y8235
7 Microprocessor, Intel Xeon E3-1220Lv3, 1.1 GHz, 4 MB cache, 1600
MHz, 13 W (2-core)
00AM097
10 DVD-ROM Drive 43W8466
10 DVD Multi burner Drive 43W8467
11 Hard disk drive, 3.5-inch simple-swap, 500 GB, 7.2 K 81Y9803
11 Hard disk drive, 3.5-inch simple-swap, 1 TB, 7.2 K 81Y9807
11 Hard disk drive, 3.5-inch simple-swap, 2 TB, 7.2 K 81Y9811
11 Hard disk drive, 3.5-inch simple-swap, 3 TB, 7.2 K 81Y9815
13 Front USB connector holder for 4U chassis 00AL691
14 Operator information panel assembly 00KA584
Thermal sensor kit 46W9221
Battery, 3.0 volt 33F8354
Cable, SAS 680R cable 00D2814
Cable, SAS 700 mm cable 00D2817
Cable, USB for 4U chassis 00Y8282
Cable, 3.5" SATA 00Y8279
Cable, 3.5" backplane signal cable 46W9217
Cable, 2.5" backplane signal cable 46W9218
Cable, 24-inch SATA 25R5635
Cable, 1 M 39R6530
Cable, 3 M 39R6532
Cable, SAS Y-cable 44E8878
Cable, USB 1 m 44E8893
Cable, USB dongle 44E8894
Cable, power supply interposer 00D8861
Cable, power supply interposer 00D2749
Cable, USB conversion 39M2909
Cable, USB 46M6475
Chapter 5. Parts listing, IBM System x3100 M5 Type 5457 167
