The following illustration is for 5U server models with 3.5" hot swap hard disk
drives installed.
6. If you are instructed to return the fan, follow all packaging instructions, and
use any packaging materials for shipping that are supplied to you.
Hard disk drive
fan duct
Guide pins
Latches
Latch holes
Figure 125. 2.5" hard disk drive fan duct removal for 5U server model with hot-swap power
supplies
Hard disk drive
fan duct
Guide pins
Latches
Latch holes
Figure 126. 3.5" hard disk drive fan duct removal for 5U server model with hot-swap power
supplies
224 System x3100 M5 Type 5457: Installation and Service Guide
