Chapter 4
Autotesting
4-17
5. Select to rename the current test. The Save Test screen will appear
with a new name option.
Note: The default Save As… name is derived from the cable name entered into the
Cable ID screen, or from the previous saved name.
6. Press Enter to accept the change and return to the Test Results screen.
Viewing or Deleting Stored Autotest Results
Test Results contain stored data from Autotest up to 6,000 Autotests can be
stored in internal memory. You can view, print, delete or rename these files.
When an Autotest or an individual test from Analyze is saved, the data is stored
with a unique name. Test results can be viewed, printed, or deleted from the
Stored Results screen.
1. On the Ready screen, select
Stored Results to open
the Job List screen.
2. Highlight the desired Job.
3. Select to choose the
desired Job.
4. Select to open the
Options screen.
To Next Page
