FC9Y-B1726 27-15
27: F
LOW
C
ALCULATION
I
NSTRUCTIONS
(5) D2 (Destination 2): Logged Data
Specify the device to store the data that is logged. A maximum of 212 continuous words are used starting from the set
device.
Note: The number of data registers that are used for logged data changes according to the maximum amount of logged data.
The number of data registers used for logged data is 2+6×the maximum amount of logged data.
Storage
Destination
Function Description Data Range
D2+0 Amount of logged data Stores the amount of logged data that has been recorded. W (word): 0 to 35
D2+1 Reserved — —
D2+2
D2+3
Log 1
Log time
When the log execution input (S3) changes from off to on (during log
updating), these devices store the content of special data registers
D8008 to D8014 (current calendar/time values) converted to the
number of seconds
*1
from January 1st, 1970.
D (double word):
0 to 4,294,967,295
*2
D2+4
D2+5
Accumulated
flow volume
When the log execution input (S3) changes from off to on (during log
updating), these devices store the accumulated flow volume.
For the processing when an accumulated flow volume overflow or
underflow has occurred, see "Carry and Borrow in Floating-Point Data
Processing" on page 3-8.
F (float):
0, 1.175494E-38 to
3.402823E+38
*2
D2+6
D2+7
Accumulated
time
When the log execution input (S3) changes from off to on (during log
updating), these devices store the accumulated time.
The unit is "s".
D (double word):
0 to 4,294,967,295
*2
D2+206
D2+207
Log 35
Log time
Same as log 1. Same as log 1.
D2+208
D2+209
Accumulated
flow volume
D2+210
D2+211
Accumulated
time
*1 The time expressed as the number of seconds from 00:00:00 on January 1st, 1970.
(For example, if the date/time is 00:00:00 on January 1st, 2015, the value is 1,420,070,400 seconds.)
*2 The upper and lower data registers change according to the 32-bit data storage method specified. For details, see Chapter 3 "Instructions
Reference" - "32-bit Data Storage" on page 3-9.
To Next Page
