10 Installation, Support, and Maintenance Guide
Evolution X1 Satellite Router
X1 Router (Indoor) Specifications
3.1 X1 Router (Indoor) Specifications
3.1.1 Mechanical and Environmental Specifications
The X1 Router (Indoor) mechanical and environmental specifications are defined in Table 3-1.
3.1.2 Power Specifications
Table 3-2 provides the power specifications for the router and the typical BUC/LNB for the X1
Router (Indoor).
Table 3-1. X1 Router (Indoor) Mechanical and Environmental Specifications
Category Description
Dimensions W 9 in (22.86 cm) x H 1.8 in (4.6 cm) x D 6.8 in (17.3 cm)
Weight 1.8 lbs (0.82 kg)
Heat Dissipation 10 W (34.2 BTU/Hour)
Airflow Natural Convection Cooling
Ambient Temperature
Operational 32F to 122F (0C to 50 C) at Sea Level
Altitude
Operating
Storage
 10,000 feet (3048 m)
 35,000 feet (9144 m)
NOTE: Only use the iDirect approved and provided power supply.
Table 3-2. X1 Router (Indoor) Power Specifications
Category Description
Power Supply Input Voltage
Range
Option 1 (AC Power Supply): 100-240 VAC Single Phase to 24 VDC, 18
AWG, country dependent
Option 2 (DC Power Supply): 12-36 VDC
Frequency Option 1 (only): 47-63 Hz
Power Supply Power
Consumption
Option 1: 1.2 A (TYP)
Option 2: 9 A (MAX)
Router Input Power +24 VDC, 2.7 A (MAX)
DC Power Consumption 36 W (TYP), 65 W (MAX)
DC Power @ Tx Output +24 VDC @ 1.5 A (MAX)
DC Power @ Rx Input +24 VDC @ 300 mA (MAX)
