iDirect X1 - RF Specifications; Table 3-6. X1 Outdoor Router RF Specifications

Installation, Support, and Maintenance Guide 15
Evolution X1 Satellite Router
X1 Outdoor Router Specifications
3.2.3 RF Specifications
The X1 Outdoor Router RF specifications are defined in Table 3-3.
Table 3-6. X1 Outdoor Router RF Specifications
Category Description
Frequency Range
Transmit
Receive
950-1700 MHz, Composite Power 0 dBm/-30 dBm
950-2150 MHz, Composite Power -5 dBm/-65dBm
Frequency Tuning Step Size
Transmit
Receive
0.6 Hz
Sub-Hertz with Demodulator
RF Power Range
Transmit
Receive
-30 dBm to 0 dBm
Single Carrier Input Power:
Minimum: -130 +10Log(Symbol Rate) dBm to - 5 dBm
Pmax = 0 dBm (MIN), 30 dB attenuation adjustable in 1 dB steps
Composite Wideband Input Power: -5 dBm (MAX)
RF Power Adjustability
Transmit
Receive
1.0 dB Nominal Step Size
Under AGC for all valid Rx input power range
Typical Transmit and Receive
Phase Noise (dBc/Hz) at
Typical Phase Jitter at
14 KHz to 1 MHz
 1.8 rms
Transmit Carrier Suppression  40 dBc (MAX)
Discrete Spurs, harmonics and
non-harmonics
 50 dBc, with output  -15 dBm Inband 32 dBc
Modulator Spectral Shaping DVB-S2 (ETSI EN302307)
Transmitter On/Off  50 dBc, with output power  -15 dBm
Frequency Phase Noise
1 KHz -75
10 KHz -85
100 KHz -95
1 MHz -105
