50 Installation, Support, and Maintenance Guide
Evolution X1 Satellite Router
Preparing the PC/Laptop for Connection to the X1 Outdoor Router
6.11 Preparing the PC/Laptop for Connection to the X1
Outdoor Router
See Section 4.2, X1 Outdoor Router Interfaces on page 20 for more information about the
interface connectors.
Ensure that the PC/laptop:
• Has an IP address that is on the same subnet of the X1 Outdoor Router
• Includes a Network Interface Card (NIC) connected with a CAT 5 cable to the 10/100 LAN
port of the X1 Outdoor Router
• Has a Web browser installed
6.12 Front Panel Power Indicator and Web Interface
LED Status Indicators
The X1 Outdoor Router has a single LED light on the front panel signifying that the power is
either on or off, with a solid red LED meaning . However, the Web Interface software (Web
iSite) displays a detailed status interpretation with a virtual panel of four LED status
indicators. Section 6.12.1, on page 50 and Section 6.12.2, on page 50 describe the functions
and display indicators for the physical front panel LED and the four virtual LEDs displayed in
the Web Interface software, respectively.
6.12.1 Front Panel Power Indicator
A single LED on the front panel of the X1 Outdoor Router displays power status as described in
table Table 4-3 on page 21.
6.12.2 Web Interface LED Status Indicators
For diagnostic purposes, the X1 Outdoor Router displays as having four “LED” indicators in the
Web Interface software (see Related Documents on page xiii, iDX Web iSite User Guide). The
four software interpreted “LED” indicators are described below:
• RX LED indicates the transmitter status
• TX LED indicates the receiver status
• NET LED indicates the network acquisition status
• POWER LED indicates whether the unit is powered on or off
NOTE: The Web Interface )Web iSite) always shows 4 simulated LEDS, although
the outdoor unit has a single POWER LED.
NOTE: The LED displayed colors (red, yellow, green) indicate the state of the
X1 Router and are documented in the iDX Web iSite User Guide, iDX Satellite
Router Installation and Commissioning Guide, and iDX Release Notes. The
definitions of the states may be software version dependent.
