14 Installation, Support, and Maintenance Guide
Evolution X1 Satellite Router
X1 Outdoor Router Specifications
3.2.2 Power Specifications
The X1 Outdoor Router power specifications are defined in Table 3-2.
NOTE: Only use the iDirect approved and provided power supply.
NOTE: The power supply provides power to the external Power Module. The
Power Module supplies DC power only to the X1 Outdoor Router.
Table 3-5. X1 Outdoor Router Power Specifications
Category Description
Power Supply Input Voltage
Range
Option 1: 100 - 240 VAC
Option 2: 12-36 VDC
Option 3: 36-76 VDC
Frequency Option 1 (only): 50-60 Hz
Power Supply Power
Consumption
Option 1: 1.2 A (TYP)
Option 2: 9 A (MAX)
Option 3: 3 A (MAX)
Router Input Power +24 VDC, 2.7 A (MAX)
DC Power Consumption 36 W (TYP), 65 W (MAX)
DC Power @ Tx Output +24 VDC @ 1.5 A (MAX), 10 MHz Reference
DC Power @ Rx Input +24 VDC @ 300 mA (MAX), 22 KHz tone
Protection Internal, primary current fuse (on-board fuse protection in the outdoor
Power Module)
Over current protection
Short circuit protection
Power Factor Correction Option 1 (only): Complies with EN61000-3-2 and EN61000-3-3
Input Transient Response 4% (recovery within 1% less than 500 m/sec for 50-75% and 75-50% load
step)
Router Input Power
Connector
IP67 Connector
Power Cord Option 1: 18 AWG (American Wire Gauge), country dependent
Option 2 and 3: 14-18 AWG
Efficiency 85% (AVG)
