Installation, Support, and Maintenance Guide 29
Evolution X1 Satellite Router
Powering on the X1 Router (Indoor)
For an X1 Router (Indoor) using the DC power supply (Option 2), see Appendix D, DC Power
Supply Installation on page 69 for assembly details:
1. Set the X1 Router (Indoor) power module switch to the OFF position (0).
2. Strip approximately 1/4 inch (.6 cm) of insulation from the ends of three appropriately
sized (14-18 AWG) DC input wires. For details see Appendix D, DC Power Supply
Installation on page 69.
3. Loosen the three screws on the terminal block plug (included, P/N Phoenix 1754465).
Insert DC (-), DC (+), and ground wires into the corresponding terminals of the DC
terminal block plug. Fasten securely. Do not over-tighten. For details see Appendix D, DC
Power Supply Installation on page 69.
4. Assemble the cable entry housing (included for cable strain relief, P/N 1803947 DigiKey
277-5758-ND) around the three DC wires and terminal block plug, locking pieces securely
with the provided cable tie. Appendix D, DC Power Supply Installation on page 69.
5. Insert the finished terminal block plug, with the cable entry housing, into the terminal
block header in the power supply.
6. Set the X1 Router (Indoor) power module switch to the ON position (1).
5.6 Powering on the X1 Router (Indoor)
This section describes powering on the X1 Router (Indoor).
5.6.1 Checking Conditions before Powering Up the System
Before powering up the system, verify that no RF coax cables are connected to the TX and RX
ports on the rear of the chassis.
Also verify that an Ethernet cable connects the LAN port of the PC/laptop to the LAN port of
the X1 Router (Indoor).
NOTE: The DC source to DC Power Module rating and capacity must be 12-36 V
DC, 9 A.
NOTE: Per IEC60950-1, the Input voltage is SELV: double/reinforced insulation
must be provided between AC Mains and SELV.
CAUTION: Do not connect or disconnect the Tx or Rx IFL cable during the time the
X1 Router (Indoor) is being powered on; this action may result in damage to the
BUC, LNB, and/or X1 Router (Indoor).
