Evolution X1 Satellite Router
Monitoring the LEDs
5.8 Monitoring the LEDs
The X1 Router (Indoor) has one LED on the front panel, see Table 4-1 on page 18 for a detailed
description of the states of the LEDs. For diagnostic purposes, the X1 Router (Indoor) displays
four LEDs in the Web Interface software (see, iDX Web iSite User Guide):
• RX LED indicates the receive status
• TX LED indicates the transmit status
• NET LED indicates the network acquisition status
• POWER LED indicates whether the unit is powered on or off
NOTE: The LED displayed colors (red, yellow, green) indicate the state of the
X1 Router and are documented in the iDX Web iSite User Guide, iDX Satellite
Router Installation and Commissioning Guide, and iDX Release Notes. The
definitions of the states may be software version dependent.
