11. Prepare the PC/Laptop as directed in Section 6.10.1, Checking Conditions before
Powering Up the System on page 48.
12. Monitor the LED indicators with the Web Interface (Web iSite) as directed in Section 6.12,
Front Panel Power Indicator and Web Interface LED Status Indicators on page 50.
13. Configure the router as indicated in Section 6.13, Configuring the X1 Outdoor Router on
page 51.
14. If the router needs repacking or maintenance see Section 7, Maintenance on page 53.
6.2 Unpacking X1 Outdoor Router Equipment
The X1 Outdoor Router and related equipment, may be shipped in one or more containers,
depending on the type of bundle purchased. Once all of the boxes have been received,
perform the following tasks:
• Place the boxes so they are facing upward: refer to the box orientation arrows on the
shipping container
• Inspect all shipping containers
• If any damage or other signs of mishandling are evident, inform the carrier and either
iDirect or the reseller
• Remove the tape and any exterior covering from the box lid
Remove items from the box only as needed. Confirm the X1 Outdoor Router components and
accessory items listed on the order form have been received, including the optional
equipment ordered. See Section 6.3, Components Typically Included in an Order on page 35
for the packing list.
6.3 Components Typically Included in an Order
Prior to installation, account for all necessary components for a complete VSAT installation. If
any items are missing or damaged, contact the Network Operator/Distributor for
replacement.
A typical installation includes the following:
• One X1 Outdoor Router
• One Power Module, either Option 1, 2, or 3, with connectors, see Section 6.4, on page 36
• Two (2) hardware mounting kits (one for the X1 Outdoor Router and one for the power
module for wall or pole mounting, see Figure 6-1 on page 36, items labeled A and E:
• Package item labeled A: (part number GTT:GLBAC-WALLMOU-SCC-M) with M6
screws for the X1 Outdoor Router mounting plates
• Package item labeled E: (part number GTT:GLBAC-WALLMOU-SCC) with M5 screws
for the Power Module mounting plates
• One (1) power module gland, package also includes a small Allen wrench, see Figure 6-1
on page 36, item labeled B
NOTE: Save the X1 Outdoor Router shipping boxes after unpacking the system.
These boxes will be needed in the event of moving or shipping the system in the
future.
